| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Effective Pixel |
1920(H) ×1080(V) |
| Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR |
| White Balance |
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC |
Auto / Manual |
| WDR |
120dB |
| Digital Noise Reduction |
3D DNR |
| Backlight compensation |
BLC |
| Shutter Speed |
1 ~ 1/30,000s |
| Day & Night |
IR Cut Filter |
| Digital zoom |
16X |
| Focus Mode |
Auto / Semiautomatic / Manual |
| Privacy Mask |
24 programmable privacy masks |
| Regional Exposure |
Support |
| Regional Focus |
Support |
| Rapid Focus |
Support |
| Lens |
| Focal Length |
4.8 mm to 120 mm, 25× optical |
| Zoom Speed |
Approx. 4.8 s (optical lens, wide-tele) |
| Angle of View |
Horizontal field of view: 58.4° to 2.7° (wide-tele)
Vertical field of view: 33.8° to 1.5° (wide-tele)
Diagonal field of view: 65.6° to 3.1° (wide-tele)
|
| Min. Working Distance |
10 ~1500mm (Wide-Tele) |
| Aperture Range |
F1.2 ~ F2.8 |
| Pan and Tilt |
| Pan / Tilt Range |
Pan: 360° endless; Tilt: -10° ~ 90° (Auto Flip ) |
| Pan / Tilt Speed |
Pan manual speed: 0.1° ~ 210°/s, Pan preset speed: 280°/s
Tilt manual speed: 0.1° ~ 150°/s, Tilt preset speed: 250°/s |
| Proportional Zoom |
Support |
| Number of Preset |
300 |
| Patrol Scan |
8 patrols, up to 32 presets per patrol |
| Pattern Scan |
4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory |
Support |
| Park Action |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| 3D Positioning |
Support |
| PTZ Position Display |
Support |
| Scheduled Task |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output |
| Preset freezing |
Support |
| Local Video and Audio |
| Network Interface |
1 RJ45 10 M/100 M Ethernet, Hi-PoE |
| Audio input / putput |
1-ch audio input (applicable microphone, plug-in power type), 2 to 2.4 V[p-p], 1 KΩ ± 10%, 1-ch audio output, line level, impedance: 600 Ω |
| Alarm Interface |
7-ch alarm input/2-ch alarm output |
| Alarm Linkage |
Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc. |
| BNC |
1.0V [p-p]/75 Ω, NTSC (or PAL) composite |
| RS-485 |
Pelco-P, Pelco-D, self-adaptive |
| Network |
| Max. Image Resolution |
1920×1080 |
| Frame Rate |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
60fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
| Image Compression |
Main Stream: H.265+/H.265/H.264+/H.264 |
| ROI encoding |
Main stream, sub-stream, and third stream respectively support four fixed areas. |
| SVC |
Support |
| Audio Compression |
G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| Simultaneous Live View |
Up to 20 |
| API |
Open-ended, support ONVIF, ISAPI, and CGI, support Third-Party Management Platform |
| SD Memory Card |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
| User/Host Level |
Up to 32 users, 3 levels: Administrator, Operator and Use |
| Security Measures |
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| Auto-Tracking |
Support |
| Smart Features |
|
| Perimeter Protection |
Intrusion, Line Crossing, Region Entrance, Region Exiting
Support alarm triggering by specified target types (human and vehicle)
Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc.
|
| Event Detection |
Face Detection, Audio Exception Detection |
| Smart Tracking |
Manual Tracking, Auto Tracking (support tracking specified target types such as human and vehicle), Event Tracking |
| Smart Record |
ANR (Automatic Network Replenishment), Dual-VCA |
| IR |
| IR Distance |
Up to 492ft(150 m) |
| Smart IR |
Support |
| General |
Working Temperature
/Humidity |
-40°F to 149°F (-40°C ~ 65°C)
90% or less |
| Power Supply |
24 VAC (Max. 60 W), Hi-PoE (Max. 50 W)
|
| Protection Level |
IP66 Standard; TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension |
Φ 9.65" × 14.72"(Φ 245 mm × 373.94 mm )
|
| Weight |
Approx. 13.23Ibs (6Kg) |
