- 4.1MP High Definition
- 1/3” CMOS
- 2688X1520P@20fps
- 2.8-12mm Varifocal Motorized Lens
- 42 IR LEDs up to 100ft
- 3D DNR, WDR, BLC, VCA
- Micro SD/SDHC/SDXC Card Slot
- Audio I/O, Alarm I/O
- IP67
- Junction Box Included
- DC 12V, PoE
| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @(F1.2,AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/10,000 s |
| Slow Shutter | Support |
| Lens | 2.8 - 12 mm @ F1.4, Motorized lens |
| Lens Mount | Φ14 |
| Day & Night | IR cut filter with auto switch |
| DNR | 3D DNR |
| Wide Dynamic Range | 120dB |
| Compression Standard | |
| Video Compression | H.264 / MJPEG/H.264 Zip+ |
| H.264 Type | Main Profile |
| Video Bit Rate | 32 Kbps ~ 16 Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image | |
| Max. Resolution | 2688×1520 |
| Frame Rate | 60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720) 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720) |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| BLC | Support, zone configurable |
| ROI Codec | Support |
| Network | |
| Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger | Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General | One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
| On-board Storage | Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
| Reset | Yes |
| General | |
| Working Temperature /Humidity |
-22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5.5W (Max. 7.5 W with IR cut filter on) |
| IR Range | Approx. 100ft(30 meters) |
| Weather Proof Ratings | IP67 |
| Dimensions | 3.7” × 4.1” × 10.2”(95×105×258.6 mm) |
| Weight | 2.65lbs (1200 g) |
(CMIP-9743W-SZ)
| SKU | CMIP-9743W-SZ |
| Brand | LTS |
| Shipping Weight | 1.8000kg |
| Shipping Width | 0.158m |
| Shipping Height | 0.388m |
| Shipping Length | 0.157m |
| Shipping Cubic | 0.009625000m3 |
